GFEPPT 2-16

$0

Brushes/compound:

 3ph 400V/50Hz p.f.0,8  1ph 230V/50Hz p.f.1
16.5kVA Max 6.4kVA
2 poles - 3000 RPM
 η 4/4 p.f.0.8 Gearbox rapp.ratio Driving power Recommended tractor power
% KW HP*
84.5 1:7 15.6 49
PTO speed rated PTO shaft dimensioning Mass
RPM** Nm*** kW*** KG
430 514 29 125


* Approximate recommended tractor power (multiply by 0,736 to obtain kW)

** PTO RPM necessary to obtain 50Hz

*** Torque and power values (@ 540 rpm) necessary for the correct operation of PTO shaft
