Baudouin 18kVA Diesel Generator - GFE20BSC-1
The Baudouin 18kVA Diesel Generator GFE20BSC-1 is a compact and reliable single-phase power solution ideal for smaller commercial and residential standby applications. Built with the trusted Baudouin engine at its core, this generator delivers dependable performance with fuel efficiency, reduced emissions, and quiet operation.
Equipped with a top-quality Stamford alternator and Deepsea control panel, the GFE20BSC-1 ensures smooth operation, easy monitoring, and intelligent load management. Its compact footprint and single-phase configuration make it perfect for locations with limited space or where three-phase power is not required. Whether it’s for use during power cuts or to support essential systems, this generator provides a reliable, economical solution.
| Model reference | GFE20BSC-1 (Canopied) |
| Engine | Baudouin 4M06G25/5 |
| Alternator | Stamford S0L2-U1 |
| Control panel | Deepsea DSE6120 |
| Frequency | 50Hz |
| Engine speed | 1500rpm |
| Phase / Poles | 1-Phase / 4-Pole |
Ratings
| kWe | kVA | |
| Prime Power (PRP) | 18 | 18 |
|
Standby Power (ERP) |
20 | 20 |
|
Voltage |
400/230V |
| Rated current | 41 |
| Fuel consumption | @100% load L/h 6.1 |
Overall dimensions
| Frame type | Dimensions | Weight | Base tank @100% load |
| (W x L x H) mm | kg | Litres | |
| Canopied | 1950 x 793 x 1125 |
820 | 40 |
Datasheets
| GFE20BSC-1 | Engine | Alternator | |
 |
