Perkins GFE495PLC 495kVA

ENQUIRE ABOUT THIS GENERATOR
DOWNLOAD GENERATOR DATA SHEET

As output demands increase the 251-550kVA GFE Perkins Powered range is ready to meet the challenge even in the harshest environments. Built around world class Perkins engines and incorporating Leroy Somers alternators and Deepsea controllers, this range is suitable for applications including agricultural, manufacturing, and heavy industrial.

Model reference GFE495PLC (Canopied) / GFE495PLO (Open)
Engine Perkins 2506C-E15TAG1
Alternator Leroy Somer TAL-047-B
Control panel Deepsea DSE4520
Frequency 50Hz
Engine speed 1500rpm
Phase / Poles 3-Phase / 4-Pole


Ratings

kWe kVA
Prime Power (PRP) 360 450
Standby Power (ERP)
396 495

Voltage
400V
Rated current 650 Amps
Fuel consumption @100% load L/h 99



Overall dimensions

Frame type Dimensions Weight Base tank
@100% load

(L x W x H) mm kg Litres
Canopied 4600 x 1422 x 2530 5000 970
Open 3850 x 1150 x 2130 3650 1000


Datasheets

 GFE495PLC Engine Alternator
Housing:
Tank:
