Cummins 30kVA Diesel Generator - GFE33CSC

Call Now kVA Calc

Unlock reliability with GFE Power Products' bespoke line of Cummins-powered diesel generators, showcasing the esteemed Cummins engine and Stamford alternator. Crafted for durability and priced accessibly, our GFE Cummins Powered generators range from 20kVA to 650kVA.

Model reference	GFE33CGC (Canopied)
Engine	Cummins 4B3.9-G12
Alternator	Stamford
Control panel	Deepsea DSE6120
Frequency	50Hz
Engine speed	1500rpm
Phase / Poles	3-Phase / 4-Pole

Ratings

	kWe	kVA
Prime Power (PRP)	24	30
Standby Power (ERP)	26	32.5

Voltage	400V
Rated current	43 Amps
Fuel consumption	@100% load L/h 8
Noise Level	72 dB(A) @ 7m

Overall dimensions

Frame type	Dimensions	Weight	Base tank @100% load
	(L x W x H) mm	kg	Litres
Canopied	2150 x 985 x 1420	1070	80
Open

Datasheets

Generator:	Engine:	Alternator:
30kVA GFE33CSC	Cummins 4B3.9-G12	Stamford S0L2-P1
